Mixtron Liquid Mixing and Dosing Pump – Efficient Non-Electric Dosing Solution

1. Introduction to Mixtron Mixing and Dosing Pump

In many industrial sectors, accurate chemical mixing and dosing play an important role in ensuring product quality and optimizing operating costs.

The Mixtron liquid mixing and dosing pump is an advanced solution that operates entirely by water flow pressure, without using electricity, enabling automatic suction – mixing – dosing of chemicals with high accuracy and stable operation.

2. What is a Mixtron Dosing Pump?

The Mixtron pump is a mechanical chemical dosing device that uses the energy from water flow to create suction force and mix the solution according to a preset ratio.

The device is typically installed directly on the pipeline and is capable of:

• Suction of chemicals from the tank
• Mixing at an accurate ratio
• Supplying a uniform solution

3. Structure of the Mixtron Mixing Pump

The Mixtron pump has a simple yet durable structure, including the following main components:

• Pump body: made of engineering plastic (POM, Poly-mix)
• Piston: creates suction and discharge movement
• Seals: ensure tightness and prevent leakage
• Check valves: control the flow direction
• Chemical suction port
• Water inlet and mixed solution outlet

This optimized design ensures stable operation in industrial environments.

4. Operating Principle (Non-Electric)

The pump operates based on water flow pressure:

1. Water flows through the pump body → generates force to drive the piston
2. The piston moves up and down → creates suction for chemicals
3. Chemicals are drawn into the mixing chamber
4. The solution is mixed according to the preset ratio
5. The mixture is discharged at the outlet

👉 This process occurs continuously, without electricity, ensuring energy saving and safe operation.

5. Technical Specifications & Flow Range

Mixtron provides multiple models with various flow ranges:

• 750 – 3,000 L/h
• 5,000 – 9,000 L/h
• 9,500 – 13,000 L/h
• Operating pressure: depends on water system
• Suction lift: approx. 4 meters
• Horizontal suction length: approx. 20 meters

6. Dosing Ratio

The pump allows flexible adjustment of multiple ratios:

• 0.03% – 0.3%
• 0.2% – 2%
• 0.5% – 4%
• 1% – 10%

👉 Suitable for a wide range of applications from low concentration dilution to high dosing requirements.

7. Models & Connection Types

Mixtron pumps are available with different connection sizes:

• 3/4” BSPT
• 1 1/2” BSPT
• 2” BSPT

Installation types:

• Wall-mounted
• In-line installation
• Floor-mounted (large models)

8. Key Advantages

✔ No electricity required – safe and energy-saving
✔ Accurate and stable dosing
✔ Easy installation and operation
✔ Durable materials with corrosion resistance
✔ Low maintenance requirements
✔ Fully automatic operation
✔ Compatible with various chemicals

9. Industrial Applications

Mixtron pumps are widely used in:

• Metal working (coolants, cutting fluids)
• Livestock (vitamins, medication dosing)
• Agriculture (fertigation systems)
• Car washing and industrial cleaning
• Water treatment
• Disinfection and sanitation

10. Accessories and Optional Items

Mixtron provides a wide range of accessories:

• By-pass systems
• Connection valves
• Filters
• Suction hoses
• Spare parts kits (seals, springs…)
• Tightening tools

👉 These accessories help optimize operation and extend equipment lifespan.

11. Selection Guidelines

When selecting a Mixtron pump, consider:

• System water flow rate
• Required dosing ratio
• Type of chemical
• Pipe size

👉 Recommendation:

• Small system → 750–3000 L/h
• Medium system → 5000–9000 L/h
• Large system → 9500–13000 L/h

The price of Mixtron pumps depends on:

• Model
• Flow rate
• Material
• Included accessories

👉 For an accurate quotation, please provide your system specifications to receive the most suitable solution.
